FCC / CGO Self Cleaning Filter Automatic Operation 30-6500M³/H For Fine Chemical
|Housing Material||304/316L/CS||Filtration Degree||50-2000μm|
|Viscosity||1-800000cps||Flowrate Rang||30-6500 M³/h|
Self Cleaning Strainer,
Industrial Water Filter,
active carbon filtration self cleaning filter
FCC and CGO Self Cleaning Filter, DFA Series for Active Carbon Filtration
When processing water and water-like liquids where a low initial investment is demanded, this series delivers tremendous benefits.DFA series pneumatic scraping self-cleaning filter ( DFA FILTER for short), is ideal for highly viscous, abrasive, or sticky liquids. The DFA FILTER operate at a consistently low differential pressure and deliver simple, reliable operation in which a low initial investment is a key driving factor. It automatically removes the particles and impurities from the filter element internal surface by mechanical scraping and it can continuously work on-line. DFA is designed for filtration of high viscosity up to 800,000mPa.s. The filtration degree ranges from 50~1500μm. It can scrape the impurities off the filter element surface most quickly, which makes it more efficiently removing the impurities. It is applicable for water and various viscous liquid. The DFA filter is designed and manufactured by following LIVIC's high performance, high quality and high reliability standard. It is a world-class quality filter.
The conventional filters get clogged frequently when filtering the viscous liquid and removing the soft impurities. The customers have to select larger filters or clean the filter manually and freqeuntly, which means expensive investment, hard work, valuable liquid loss. DFA filter solves these kinds of problems by its advanced self-cleaning principle. It always keeps the filter element clean, discharges waste liquid with high impurity concentration, reduces the liquid loss. When filtering the viscous liquids such as dirty water, adhesives, resins, polymers and oils, DFA filter works more efficiently. DFA filter is taking place of the vibrating screen, bag filter, basket filter and some kind of back-flushing filter by its technical advantages and low running cost.
|Filter Main Type||DFA7||DFA22||DFA41||DFA71||DFA213||DFA284|
|Filter Element Qty.||1||3||4|
|Applicable Liquid||water and viscous liquid (<800000cps),impurities content<1000ppm|
|Standard Design Pressure||1.0MPa,higher design pressure available|
|Design Temperature||0-200℃(determined by seal materials)|
|Cleaning D.P.||50-100KPa(differs by the liquid viscosity)|
|D.P. Instrument||pressure transmitter / differential pressure transmitter|
|Inlet&Outlet Standard||HG20592-2009 Flange(standard, DIN compatible ), HG20615-2009 Flange ( ANSI B16.5 compatible)DIN11851 sanitary coupling, female thread|
|Filter Element Series||MS/NS/AS|
|Housing Seal Material||NBR/EPDM/VITON/Silastic/FEP encapsulated Silastic|
|Element Seal Material||NBR/EPDM/VITON/Silastic/FEP encapsulated Silastic|
|Piston Rod Seal Material||NBR/PU/VITON|
|Purging Valve||Full-port pneumatic ball valve, single action or double action, material 304/316|
|Facility Supply Requirement||220V AC for control system, 0.4-0.6MPa clean and dry compressed air|
jacket design for thermal oil or steam, keep the temperature and fluidity
ing the instruments and control system, for flammable and explosive applications
■ Applicable Industries: petro-chemical, fine chemical, pulp and paper, food and beverage, water treatment, etc.
■ Applicable Liquid Types: wax, coal oil, monomer, polymer, citric acid, fermented broth, cosmetics, silicon solution, soap, sorbitol, steriodsugar, wet end additives, adhesives, inks, lubricating oils, coatings, resin, rubber, ethanol, miscella, edible oil, juice, diesel, etc.
TECHNICAL FEATURES AND ADVANTAGES
■Up-and-down reciprocating scraping, scrape impurities off directly, especially good at viscous liquid filtration and removing viscous suspending impurities
■Simple structure, easy disassembly, pull the filter element out easily after removing the scraper, easy for internal cleaning
■Automatic operation, continuously on-line filtration, terminate the hard work of filter element replacement and cleaning
■No disposable filter media, save the cost of filter media consumption and the environment treatment
■Very low filtration pressure drop, steady flow rate, save the energy, good for keeping the process continuous and steady
■Closed filtration, prevent danger of liquid leakage, good for safety production and operator’s health
