Disc Cleaning Scraper Filter 1 - 800000cp Viscosity For Marine Paint Filtration

Place of Origin Shanghai
Brand Name LIVIC
Certification SGS, ISO9001
Model Number DFM
Minimum Order Quantity 1 pc
Price Negotiation
Packaging Details Polywood cases
Delivery Time 60 work days
Supply Ability 15pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Housing Material Ss304,ss316L, CS Filtration Rating 0.025-3mm
Viscosity 1-800000cp Design Pressure 1000Kpa
Design Temperature 200℃ Style Vertical Or Horizontal
High Light

Auto Clean Filter

,

Industrial Filtration Equipment

,

Marine Paint Filtration Scraper Filter

Leave a Message
Product Description

Automatic Self-cleaning Scraper Filter DFM Series for Marine Paint Filtration





Description



DFM series scraping self-cleaning filter (DFM filter for short), automatically removes particles from the filter element surface by the efficiently mechanical scraping, can work on-line continuously, consumes no disposal filter media, requires no frequent manual cleaning, is capable of the filtration for both normal and high viscous liquids. DFM series, the motor drives the scraper to rotate and remove the particles on the filter element internal surface. DFM series are good for the high viscous liquid.



Specifications:



Filter Main Type DFM22 DFM41 DFM71
Filter Area(c㎡) 0-7140
Volume(L) 0-175
Filtration Degree 100-3000μm
Design Temperature 0-200℃(determined by seal materials)
D.P. Instrument pressure transmitter / differential pressure transmitter
Inlet&Outlet Standard HG20592-2009 Flange(standard, DIN compatible ), HG20615-2009 Flange ( ANSI B16.5 compatible)DIN11851 sanitary coupling, female thread
Housing Wet Part Material 304/316L/CS
Housing Seal Material NBR/ VITON /PTFE



Applications:



Applicable industries: Water treatment, pulp and paper, petro-chemical, bio-pharmaceutical, coatings, inks, oil refinery, food and beverage

Typical applicable liquid: Wax, coal oil, monomer, water, citric acid, fermentation broth, protein, soap, wet end additive, coating, ink, adhesive, rubber, ethanol, chocolate, confectionary, juice, coolant, etc.
