Versatile Liquid Bag Filter Housing BFS Series Side In Single Bag For Pharmaceutical

Place of Origin China
Brand Name LIVIC
Certification ISO9001/SGS
Model Number BFS
Minimum Order Quantity 1 pc
Price Negotiation
Packaging Details wooden case
Delivery Time 30 days after received your payment
Payment Terms T/T
Supply Ability 800 pcs per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Style Vertical Motive Force Pressure
Type Manual Filter Filter Bag Size 1#,2#,4#
Pressure Rating 10Bar Filtration Rating 1-2000μm
High Light

Water Filter Housing

,

Stainless Filter Housing

Leave a Message
Product Description

Versatile Cost-effective Flowline Liquid Bag Filter Housing BFS Series





Description



BFS Series Side-in Single Bag Filter (BFS FILTER for short) is manufactured referring to the GB150 pressure vessel standard. BFS Series is a full-featured investment-cast filter vessel. A sand blasted finish that makes cleaning complete and a cover that can be easily adapted to different opening directions are among BFS many value added features. The high strength structure delivers absolutely high safety when filtering the dangerous liquids. It is an ideal durable filter for all the demanding application. The housing design pressure is high up to 2.0MPa. Various inlet and outlet sizes and layouts are optional for the convenient installation.



Specifications:



Main Model BFSA1 BFSB1
Design Pressure ( MPa ) 1.0/1.6/2.0
Design Temperature ( ℃ ) 0-250①
Filter Bag Size ( mm ) φ178X419 φ178X813/φ178X720
Filter Area ( ㎡ ) 0.25 0.5/1.0
Flowrate ( m³/h ) 12.5② 25②
Filtration Rate ( μm ) 1-2000
Casting Cover Material CF8/CF8M
Housing Material 304/316L
Support Legs, Bolts & Nuts Material SS
Seal Material NBR/EPDM/VITON/Silastic/PTFE encapsulated Silastic/PTFE
Outside Surface Finish Bead Blasted
Inside Surface Finish 120Mesh Polishing ( Standard ), Food Grade Polishing, Halar Coating, PA11 Coating
Standard Inlet & Outlet Connection Flange HG20592-2009( DIN )
Optional Connection Flange HG20615-2009 ( ANSI ), NPT, Standard Sanitary Clamp
Inlet and Outlet Size DN40/DN50/DN65/DN80/DN100
Approx. Volume ( L ) 18 32

①The design temperture is also determined by the seal material and the filter bag material

② The typical flowrate for the clean water filtration at 10 micron. Consider the filtration degree,

viscosity and contaminent content when filtering the different liquid.



Applications:

  • Food and Beverage
  • Chemical Processing
  • Paints, Inks, Resins and Coatings
  • Electronics
  • Petrochemicals
  • Municipal Water Treatment
  • Industrial Water Treatment
  • Pulp and Paper
  • Pharmaceutical
  • Lubricants, Metalworking Fluids
  • Solvents



Technical Features and Advantadges



■ Precise casting cover, solid, durable and reliable
■ Various inlet and outlet size( DN25-DN100 ) availabe for different flowrates
■ Three types of inlet and outlet layout optional for easy pipeline design and installation
■ Standard size flange, excellent equipment strength and nozzle loading ability
■ Quick-Open design, loosen the eye-bolt and nut and open the cover, simple maintenance
■ Reinforced eye-bolt seat, no deformation under 1.6 MPa
■ Made of quality 304 or 316 stainless steel
■ Good welding quality, durable and safe
■ Concave cover, reduce volume and low liquid level, no liquid overflow pollution.
■ Solid stainless steel eye-bolts and nuts, corrosion resistance, durable and reliable
■ Adjustable stanless steal support legs, simple installation
■ Bead blasted external surface, easy to clean, nice surface finish



Available Options

  • Steam jacket
  • Mounting brackets
  • Electro polishing

Dimension

Versatile Liquid Bag Filter Housing BFS Series Side In Single Bag For Pharmaceutical 0

Type Inlet&Outlet A B C D E
DN mm mm mm mm mm
BFSA1 50 537 190 764 219 560
BFSB1 50 897 190 1124 219 560
BFSC1 25 480 127 650 133 350
