1.0MPa Self Cleaning Metal Edge Filter DFX Series For Monomer Honey Filtration
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|V-slot Series, POR Series
1.0MPa Self Cleaning Metal Edge Filter,
Monomer Metal Edge Filter,
Honey Metal Edge Self Cleaning Filter
Self-cleaning Metal Edge Filter DFX Series for Monomer and Honey Filtration
Self-cleaning Metal Edge Filter DFX Series (DFX Filter for short), is the high efficiency self-cleaning filter independently developed by LIVIC. The DFX self-cleaning filter can be used for a variety of low to high viscosity liquids, pastes, and similar materials. Compact designs with one or more rotating elements offer ideal conditions for selecting the optimal model size. They come in a variety of designs and materials, facilitating a wide choice of applications - including high-pressure designs. Minor adaptations to available standard solutions frequently satisfy customer-specific requirements.Removing the impurities particles on the filter element outside by mechanical scraping, it continuously filters on-line.DFX filter is designed for fine and accurate filtration ranging from 50-500micron. It can avoid extruding and breaking the impurities and is capable of the filtration for water and liquids of viscosity up to 800000cps. DFX filter is designed and manufactured per LIVIC’s high performance, high quality and high reliability standard. It is a world-class quality filter.
Applicable Industry: oil and fats, water treatment, pulp and paper, petro-chemical, fine chemical
Applicable Liquids: wax, kerosene, monomer, polymer, citric acid, fermented broth, cosmetics, silicon solution, soap, sorbitol, steriodsugar, wet end additives, adhesives, inks, lubricating oil, coatings, resin, rubber, ethanol, miscella, diesel, etc.
|water and viscous liquids(<800000cps), impurity<1000ppm
|Standard Design Pressure
|1.0 MPa, high design pressure available
|0-200°C( determined by the seal material)
|Filter Area Per Filter
|Cleaning Differential Pressure
|Differential Pressure Instrument
|differential pressure tansmitter(DPT) or diffential pressure switch(DPS)
|180w, three phase, 380V, protection class IP 55; worm reduction gear
|Inlet and Outlet Standard
|flange, HG20592-2009(DIN compatible), HG20615-2009(ANSI B16.5 Compatible)
|Filter Element Type
|V-SLOT slotted metal filter element, 316L material
|Housing Wet Part Material
|Scraping Blade Material
|Housing Seal Material
|Pneumatic ball valve, protection class IP65
|Supply Facility Requirement
|380V AC,0.4-0.6MPa clean and dry compressed air
