Manual Bag Filter Housing Vertical Style 304L / 316L For Beverage Filtration

Place of Origin China
Brand Name LIVIC
Certification ISO9001/SGS
Model Number BFT
Minimum Order Quantity 1 pc
Price Negotiation
Packaging Details wooden case
Delivery Time 30 days after received your payment
Payment Terms T/T
Supply Ability 800 pcs per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Housing Material 304, 316L Application Chemical Industry,Environmental Protection
Style Vertical Motive Force Pressure
Type Manual Filter Origin Shanghai
High Light

Single Bag Filter


Stainless Filter Housing

Leave a Message
Product Description

Absolute Sealing Basket Filter Housing for Beverage Filtration





BFT Series Single Bag Filter (BFT filter for short ) features over-the-top flowing-in design. It is the

single bag filter with the best structure. Its absolute bag sealing design makes it ideal for the absolute

high filtration degree applications. The Solid structure delivers high safety and durability. The BFT

series bag filter is designed for the most demanding applications.




Main Model BFTA1 BFTB1 BFTC1
Design Pressure ( MPa ) 1.0/1.6
Design Temperature ( ℃ ) 0-250①
Filter Bag Size ( mm ) φ178X419 φ178X813/φ178X720 φ102X355
Filter Area ( ㎡ ) 0.25 0.5/1.0 0.1
Flowrate ( m³/h ) 12.5② 25② 6m3/h②
Filtration Rate ( μm ) 1-2000
Casting Cover Material CF8/CF8M
Housing Material 304/316L
Support Legs, Bolts & Nuts Material SS
Seal Material NBR/EPDM/VITON/Silastic/PTFE encapsulated Silastic/PTFE
Outside Surface Finish Bead Blasted
Inside Surface Finish 120Mesh Polishing ( Standard ), Food Grade Polishing, Halar Coating, PA11 Coating
Standard Inlet & Outlet Connection Flange HG20592-2009( DIN ) NPT
Optional Connection Flange HG20615-2009 ( ANSI ), NPT, Standard Sanitary Clamp
Inlet and Outlet Size DN50 DN25
Approx. Volume ( L ) 15 28 3
  • The design temperture is also determined by the seal material and the filter bag material

② The typical flowrate for the clean water filtration at 10 micron. Consider the filtration degree,

viscosity and contaminent content when filtering the different liquid.




Typical Applications water treatment prefiltration, circulating cooling system, heat exchanger protection, spraying nozzle protection, ballast water treatment system, ultrafiltration membrane protection

Applicable Liquids underground water, sea water, lake water, river water, circulating cooling water, sewage water, process water, cleaning water




■ Absolute sealing design, suitable for ultra-fine filtration

■ Seal the filter bag and the housing at the same time, simplified operation

■ Precise over-the-top horn-shape casting cover, soft flow distribution, optimized filter cake building

■ Fluent flow pipeline design, low pressure loss

■ Standard dimension flange, high strength ,safe and reliable

■ Quick-Open design, loosen the eye-bolt and nut and open the cover, simple maintenance

■ Reinforced eye-bolt seat, no deformation under 1.6 MPa

■ Made of quality 304 or 316 stainless steel

■ Minimum two welding seams on the main shell, easy to clean the interior completely

■ Outstanding welding quality, durable and safe

■ Low operation height, easy to stop to install the filter bag

■ Lower volume than the equal side-in bag filter, reduce fluid filling and waste

■ Easy and safe to pull the filter bag collar especially when filtering the dangerous or viscous liquid

■ Three types of inlet and out layout options, convenient for the installation

■ Solid stainless steel eye-bolts and nuts, corrosion resistance, durable and reliable

■ Adjustable stanless steal support legs, simple installation

■ Bead blasted external surface, easy to clean, nice surface finishManual Bag Filter Housing Vertical Style 304L / 316L For Beverage Filtration 0
